Piping Spooling Software
AUTOSPOOL is an automatic piping spooling software, used for generating piping Fabrication, Erection Isometrics & related reports. Which is based on the convenience of Fabrication / Erection work, site requirements, spool transportability. To achieve the best international construction practices and clients requirement standard.
This software generates the Fabrication / Erection construction scope in Inch Dia, Inch Meter and tonnage. It also calculates piping cut length, piping bending length, spool weight and surface area as required in the project.
Ease of Implementation
Features of AUTOSPOOL
Autospool can be fully customized as per speciﬁed requirements for complete integration with the existing processes. All the outputs like graphics, bill of materials, attributes or desired revision details, different lists like cut length, Inch Dia., Inch Meter, Weld etc. can be customized. Drawing templates can be customized as per the requirement by using the backing sheet customization module. Any company speciﬁc formats/ standards/logic’s can also be customized. AUTOSPOOL can further be customized for the desired spool numbering, weld numbering, weld setting, weld identiﬁer, weld categories, drawings, reporting and much more with Inch Dia. calculation considering reinforcement pad, branch connection, O-lets and another mode of measurement factors.
Software has feature to have 1D / 2D barcodes on generated drawings.The 1D / 2D barcode representing the spool can be automatically printed on drawing or generated separately from the barcode printer. This system has an inbuilt BARCODE printing language compatible with a ZEBRA printer. And these barcodes can be scanned directly by a barcode scanner for tracking the working status.
This software generate the most efﬁcient way of pipe cutting. Which is based on the required cutting length & the pipe material available in the store. In this way one can minimize the pipe wastage and effectively utilize the material. All cutting reports are generated and the data can be sent to the pipe cutting machine by additional customization.
The Software generate the consumable required like O2, DA, Grinding wheel, Cut off a wheel, Argon Welding, Purging gas, Root / Final ﬁller wire type and quantity. Root / ﬁnal electrodes type and quantity etc.The Software can generate manpower planning for the work to be done in fabrication and erection based on the input available
With the integration of SPOOLMAN / ERMAN the actual progress of the fabrication, material availability, erection can be shown in the 3D model. This piping software generates 3D dwg ﬁle, containing a 3D model of the pipe with all associated progress status. This can be further viewed by any third party tool for review.
The results from the AUTOSPOOL can be sent to a third party software for further communication to a CMM machine or to another in-house customized software. We are open to creating an integration with the clients existing software. Kindly get back to us for more information on the same. This Piping software is integrated with other modules of EPCPROMAN like SPOOLMAN / ERMAN for further fabrication/ erection/manufacturing and setting up of the material management.
AUTOSPOOL Product Demo
Read how AUTOSPOOL helps you to generate piping Fabrication, Erection Isometrics & related reports.
Use of AUTOSPOOL
What do you get from AUTOSPOOL?
How does AUTOSPOOL software Work ?
AUTOSPOOL works with following inputs:-
Neutral file *.idf, *.pcf, *.impf which are generated from leading plant design software but not limited to PDMS, E3D, PDS, SP3D, AUTOPLANT, PLANT3D, ISOMEC etc.
AUTOSPOOL Revision Management
Changes in engineering piping isometric is continuous and must be taken care in various stages of project planning & execution. The software has been designed to transfer changes from one to another revision by referring work done in old revision. Project are managed by providing various facilities to accommodate revision updations.
The changes information is automatically deleted & relevant changes are transferred to fabrication/erection management software (SPOOLMAN / ERMAN)
All changes are highlighted by cloud marking, colour, revision annotation and related reports output.
Welding & Spooling
Welding is the most important activity at a construction site to be planned, it governs the whole project with respect to time, volume, progress, material, cost, project management and control.
The project cost can be optimized by proper planning of welding at the site and fabrication shop. This software has several flexible options to take care of proper and efficient welding implementation on site.
The program is uniquely designed to combine multiple isometric and adapt a single isometric with respect to the company standard welding criteria. AUTOSPOOL helps to optimize field Inch Dia, locate field welds and fix field tolerance lengths to increase the efficiency of the shop & field weld management.
Support Weld, Instrument & Other Components
The software supports the detailing of the standard library including the support fabrication drawing and related MTO, planning for welding specific primary supports along with spools.
Welding preparation details, Instrument / special component installation, fabrication / erection details of instruments, supports, special tagged items etc. are managed.
